Channel Mode:34/39CH
Light Source
Lamp: OSRAM SIRIUS HRI 470W XL
Life time:1500Hours
Optical System
Advanced optical system, clear, sharp
Zoom range 2.5～45°
Gobo Wheels
Static gobo: 14 gobos + white.
Rotation gobo: 9 gobos+ white, changeable;
Animation gobo: Could be used by separately or combined with other gobo
Color Wheels
11 Colors+2700K +3200K+White+CMY Prism
Prism System
Rotation prism wheel 1 :8 Facet prism+ Linear 6 facet prism +cylindrical prism
Rotation prism wheel 2 :8 Facet prism+ Linear 6 facet prism +doule layer prism
Prism wheel 1 and Prism wheel 2 can overlay
Control & Screen
Display: Color display,4-touch buttons
Protocols: DMX512, RDM
USB connector can set DMX address with power and upgrade the software.
PAN & TILT
Pan: 540°; 8Bit/16Bit
Tilt: 270°; 8Bit/16Bit
Automatic Pan/Tilt position correction
Magnetic sensor position lock, more accurate than classic optical sensor
Electrical Info
Input voltage range: AC 100-240V, 50/60Hz
Power consumption: 600W
Power connector input
Data in/out: 3-pin and 5-pin XLR
Size & Weight
Product size: 410x250x690 mm
Flycase: 930x520x910 mm
Carton box: 800x420x500mm
N.W: 24.5 kg
G.W: 29 kg(carton box).
